面向芯片、器件與系統的先進液態金屬冷卻=ADVANCED LIQUID METAL COOLING FOR CHIP,

面向芯片、器件與系統的先進液態金屬冷卻=ADVANCED LIQUID METAL COOLING FOR CHIP,

定　　價：598 元

當前圖書已被 9 所學校薦購過！

查看明細

作者：劉靜
出版時間：2020/1/1
ISBN：9787547845325
出版社：上�？茖W技術出版社

中圖法分類：TG111.4
頁碼：
紙張：膠版紙
版次：
開本：16開

9

7

8

8

4

7

5

5

3

4

2

7

5

隨著微納電子技術的飛速發展，高集成度芯片、光電器件與系統等引發的熱障問題，已成為制約其可持續發展的關鍵瓶頸。這種發展瓶頸對先進散熱技術提出了前所未有的要求。在這種背景下，本書作者于2001年前后首次在芯片冷卻領域引入具有通用性的液態金屬散熱技術，隨后在國內外引發重大反響和后續大量研究，成為近年來該領域內前沿熱點和極具應用前景的重大發展方向之一。影響范圍甚廣，正為能源、電子信息、先進制造、國防軍事等領域的發展帶來顛覆性變革，并將催生出一系列戰略性新興產業。為推動這一新興學科領域的可持續健康發展，本書作者將其十七八年的研究成果系統梳理和總結，編撰成本專著。本書系統圍繞液態金屬散熱技術，集中闡述了其中涉及的新方法、新原理與典型應用，基本涵蓋了液態金屬芯片散熱領域中的所有重大主題，包括：液態金屬的基礎熱物理特性、流動特性、材料相容性、驅動方法、傳熱特性、微通道散熱技術、相變熱控技術以及一些實際器件的應用等方面，學科領域跨度大，內容嶄新，系國內外該領域首部著作，是一本兼具理論學術意義和實際參考價值的學術著作。以英文版推出，是為了更好地將中國原創科研成果推向國際，因此，具有非常及時和重要的出版價值。

The last two decades witness an explosive growth of personal computers，communication systems and workstations in the microelectronic industry. Meanwhile，the chip integration density is approaching its limit due tothermal barrierencountered. As is well known， overheating of a computer chip would result in shortened life， malfunction， low reliability and failure of work. Therefore， removal of the large amount of heat generated in the electronic components remains a big challenge facing modern system designers and thermal management engineers. However， most of the currently available advanced thermal management techniques are not sufficient enough to cope with the ever increasing devices power density like 100~1000 W/cm2 and the more compact package technology.
So far， tremendous efforts have been made to find out alternative methods for cooling the high power processors. Compared with the widely adopted air cooling，water cooling appears much efficient at drawing heat away from the processor and is therefore gradually becoming a major theme in developing new generation chip cooling device. With the forced convective flow of water， an improvement in heat transfer capacity over air cooling has been found to be more than a factor of 10. However，such method also implies its limitations. The small thermal conductivity of water may lower its effectiveness as a cooling fluid. Therefore，researchers are considering enhance the convective heat transfer effect of water by adding certain conductive nano particles such as copper or aluminum into the solution suspension. But improvement of the solutions heat conductivity through this way is still somewhat limited due to technical restrictions like particle oxygenation，susceptibility to fouling，particle deposition or conglomeration， degeneration of solution quality and flow jamming over the channels etc.
Realizing that a group of metals with an extremely low melting point such as gallium or its alloy have a far much larger thermal conductivity than that of the traditional coolant，at the year around 2000~2002，I came up to an idea to adopt such mediums as the cooling fluids for the thermal management of computer chip. A series of theoretical and experimental investigations have therefore been continuously carried out in my lab since then，aiming to develop the new generation liquid metal cooling category. As is now clear that，compared to the conventional heat transfer fluids，liquid metals with low melting point are rather desirable for thermal management of high power density devices owing to their large thermal conductivity and electrical conductivity，low vapor pressure，low dissolution in water and extensive temperature range over which they remain in the liquid phase. Particularly，liquid metal coolants can be pumped efficiently with compact magneto fluid dynamic（MFD）pumps，which are characterized by silent， vibration free，and low energy consumption rates because of the absence of moving components. Liquid metals can even realize high efficiency self driving through its thermosyphon effect and will offer better cooling capability than that of water under the same situations.
One thing worth of particularly pointing out is that，the normal boiling points of liquid metals are generally high，and hence the liquid metal cooling systems can be operated at near atmospheric pressures，and liquid metals can remain in liquid state at higher temperature compared to conventional fluids like water and various organic coolants which makes the design of a compact heat exchanger feasible. For example，the most classical liquid metal such as gallium has much higher evaporation point than that of water（2204.8℃ for gallium，and 100℃for water）. Therefore，it can remain in a single liquid phase within a wide temperature range. This makes it possible to break up the restriction of the critical heat flux and thus effectively prevent devices from burning out. The key advantages of using liquid metals as the coolant lie in that they do not require operation at high pressure in order to obtain high temperatures and usually， the melting temperatures are low enough such that they can be used as coolants in thermal devices. As a result，their running usually involves pressure which is small compared to thermodynamic critical pressure of the fluid.
Among various kinds of liquid metals，mercury has been used in some earlier versions of fast breeder reactors. It was ever adopted as a thermal working fluid in macroscale systems for many years， before its dangers were well understood. Besides， sodium and potassium are also very good cooling fluids， and NaK （sodiumpotassium） alloy has been widely used in fast breeder reactors. Sodium is a normal coolant used in large power stations，and both lead and NaK have been used successfully for smaller generating rigs. However，they are quite reactive to air and water，and are therefore considered fire hazards.
Unlike the above two，gallium and its alloys including those composed from bismuth and its alloy have been proven to be perfect working fluids or medium for room temperature appliances especially computer chip，LED lamp etc. It owns a high specific heat capacity per unit volume，a low vapor pressure at room temperature，a less reactive nature when exposed to oxygen and water，and a high surface tension which impedes leakage. And these features warrant the future applications of gallium in the thermal management of high heat flux density area. Gallium forms alloys characterized by specific properties with the majority of metals and metalloids. Many of the gallium based alloys are low melting. The physical and mechanical properties of some metals can be enhanced when seeded with gallium. Gallium based alloys mainly consist of gallium， indium，and tin，or two of the three types. Overall，gallium and its alloys are endowed with low toxicity and low reactivity. Therefore，they are quickly adopted as a replacement for many applications that previously employed toxic liquid mercury or reactive NaK. Further，liquid metal with low melting point， as a new generation heat transfer medium，can be easily enhanced on its conductivity through loading with more conductive nano particles. With an extremely high conductivity however relatively small viscosity，such liquid metal could serve as an idealistic base solution or thermal interface medium which shows very promising future for the thermal management application in super CPU chip cooling or the situations requesting seriously high heat flux removal.
So far， systematic knowledge about the flow and heat transfer in room temperature liquid metal is rather limited which is however extremely important for future practices. To push forward further researches and possible applications along this important frontier，This book is dedicated to summarize the latest science and art of the liquid metal cooling as advanced over the past few years. The author would like to point out that， although the research related to the utilization of liquid metals as heat transfer media has begun since nearly half a century ago，technological interests derive mainly from the potential use of liquid metals as working fluids in the nuclear reactors. Within an extremely long period of time，researches basically are limited to those specific liquids like sodium，potassium or their alloy，and mercury，which have either high melting temperature or are just toxic and dangerous. Extensively applying the room temperature liquid metals especially gallium， bismuth and their alloy as the new coolant and heat transfer medium for the thermal management of computer chip have been unfortunately overlooked until the beginning of this century. With tremendous efforts and continuous researches ever made subsequently，it is now very clear that，the heat transfer enhancement by liquid metals，as a newly emerging technology in the electronic and various high heat flux fields， offers many brand new scientific and technical opportunities worth of pursuing in the coming time.
This book is an output of our labs more than 16 yearscontinuous academic endeavours. Over the past few years， a group of our faculties， post doctorial research fellows， graduate students and collaborators have made important contributions to mould this new area of liquid metal advanced cooling. The author would like to take this chance to express his sincere appreciations to those people who have offered their professional contribution： Dr. Ma Kunquan， Dr. Deng Yueguang， Dr. Gao Yunxia， Dr. Tang Jianbo， Dr. Wang Lei， Dr. Tan Sicong， Dr. Li Haiyan， Mr. Yang Xiaohu， Mr. Ge Haoshan， Mr. Mei Shengfu， Mr. Li Peipei， Mr. Xie Kaiwang， Mr. Li Teng， Prof. Deng Zhongshan and Prof. Zhou Yixin. Further， Dr. Sheng Lei offers very helpful assistance in gathering all the copyright permissions contained in this manuscript. Lastly but not least，I would like to also acknowledge the generous support from the Special Foundation of President of the Chinese Academy of Sciences，F(xiàn)rontier Project of the Chinese Academy of Sciences as well as the National Natural Science Foundation of China.
I hope that this book could serve as start for the academics and industries to quickly grasp the basics of the liquid metal cooling and thus better advance the related areas. I would also very much welcome any critical comments and constructive suggestions from the readers for me to further enhance this book which would be incorporated into its future possible updated version.

Liu Jing
October，2018

Chapter 1Introduction1

1.1Increasing Challenges in Advanced Cooling2
1.2Water Cooling and New Alternatives4
1.3Basic Features of Conventional Heat Exchangers6
1.3.1Heat Exchanger Classification by Geometry and
Structure7
1.3.2Heat Exchange Enhancement Techniques12
1.4Limitations of Waterbased Heat Exchanger13
1.4.1Overall Properties of Water13
1.4.2Adhesion and Cohesion14
1.4.3Surface Tension14
1.4.4Specific Heat14
1.4.5Conductivity15
1.5Liquid Metal Coolant for Chip Cooling15
1.6Some Facts about Liquid Metal17
1.7Revisit of Traditional Liquid Metal Cooling19
1.8Liquid Metal Enabled Innovation on Conventional
Heat Exchanger22
1.9Potential Application Areas of Liquid Metal Thermal
Management 23
1.9.1Chip Cooling23
1.9.2Heat Recovery25
1.9.3Energy System27
1.9.4Heat Transfer Process Engineering28
1.9.5Aerospace Exploration28
1.9.6Appliances in Large Power Systems29
1.9.7Thermal Interface Material29
1.9.8More New Conceptual Applications31
1.10Technical and Scientific Challenges in Liquid Metal
Heat Transfer 32
1.11Conclusion35
References36
